Designed and manufactured to meet or exceed the accuracy and repeatability requirements of ISO 6789: 2003 (+/- 6% of setting).
Various models that range from 0.7 ozf.in - 120 lbf.in
Ergonomic rubber hand grip.
Precision radial ball clutch "slips-free" when the preset torque is reached preventing over-torquing.
Tamper-proof internal adjustment. No external adjustment scale - must be preset using a torque analyzer.
All models provide bi-directional operation.
| Model | American | S.I. | Metric | Drive |
| PSE25 | 0.7 – 35 ozf.in | 0.5 – 25 cN.m | 0.05 – 2.5 kgf.cm | 1/4" F/Hex |
| PSE150 | 3 ozf.in – 13 lbf.in | 2 – 150 cN.m | 0.2 – 15.3 kgf.cm | 1/4" F/Hex |
| PSE450 | 8 ozf.in – 40 lbf.in | 6 – 450 cN.m | 0.6 – 45.8 kgf.cm | 1/4" F/Hex |
| PSE1350* | 10 – 120 in.lbs | 100 – 1350 cN.m | 10.5 – 138 kgf.cm | 1/4" F/Hex |
*Supplied with 1/4" Sliding T-BAR
| Item | Description | Price | ||
|---|---|---|---|---|
PSE25 Torque Screwdriver 0.7 - 35 ozf.in - mz-020186 gd-062200 | $385.56 | |||
PSE150 Torque Screwdriver 3 ozf.in - 13 lbf.in -mz- 020173 gd- 062400 | $313.23 | |||
PSE450 Torque Screwdriver 8 ozf.in - 40 lbf.in - mz-020187 gd-062600 | $313.31 | |||
PSE1350 Torque Screwdriver 10 - 120 lbf.in - mz-020188 gd- 062800 | $382.50 |
